TP-Link TL-R470T+Load Balancing Broadband Router

The TP-Link TL-R470T+ Quad-WAN Load Balancing Broadband Router possesses stronger data transmission capacity, increased stability and cost-efficient ownership for networks in places such as Internet cafes and small offices.

The TP-Link TL-R470T+ has an integrated smart load balancing function over 4 WAN ports which automatically selects the most efficient line according to load and bandwidth requirements, providing users with consistent network uptime and reliable Ethernet connectivity.

Compare

The TP-Link TL-R470T+ load balance broadband router is a wise choice for small business. It brings you
high return on investment with low overhead. Featuring three changeable WAN/LAN ports,
TL R470T+ supports up to 4 WAN ports, which can satisfy various Internet access requirements
through one device. TL-R470T+ integrates multiple load balancing strategies, advanced QoS and
strong firewall to provide you with consistent network uptime and reliable Ethernet connectivity.
Moreover, it is easy to manage the TL-R470T+ via a web-based utility, which makes building and
managing your network more convenient.

Load Balancing Router – Key Features

  • Up to 4 WAN ports equipped with advanced load balance to guarantee maximum bandwidth
    and backup capabilities
  • Load Balancing automatically selects the best route to the destination according to the load
  • Captive portal provides convenient guest authentication while promoting your business
  • Abundant security features including ARP Inspection, DoS Defense, URL/Keyword Domain
  • Filter and Access Control
  • Smaller case for cost-effective solution in the small office or Internet cafes network

R470T+ Load Balancing Network Topology Example

Three Changeable WAN/LAN Ports For Flexible Load Balancing.

The TL-R470T+ features three changeable ports that can be set to either LAN or WAN, allowing the router to support up to four WAN ports to satisfy various Internet access requirements through one device. The router also has an integrated smart load balancing function which automatically selects the most efficient line according to load and bandwidth requirements, providing users with consistent network uptime and reliable Ethernet connectivity

Abundant Security Features

For defense against external threats, TL-R470T+ can automatically detect and block Denial of service
(DoS) attacks such as TCP/UDP/ICMP Flooding, Ping of Death and other related threats. Moreover, this
router provides IP/MAC/URL/Web ¬filtering functions, which forcefully prevent attacks from intruders and
viruses. For applications such as FTP, H.323, SIP, IPsec and PPTP which are not well compatible with NAT, TL-R470T+ offers administrators one-click enable of ALG choices corresponding to the above five
applications.

Efficient Access Management

Portal authentication enables administrators to only allow users with legal accounts that have passed
authentication to access the Internet. Cooperating with IP-based Bandwidth Control, it is capable of
confining bandwidth usage of certain accounts.

Safety Minded Enterprise Investment

Professional lightning protection technology is designed to prevent electrical surges from penetrating
the interior of the device, to be discharged harmlessly into the Earth. This router is designed to prevent
lightning damage of up to 4KV in the well-grounded connection conditions. This feature ensures that
networking infrastructure investments remain as safe as possible from one of Mother Nature’s more
violent elements.

TP-Link TL-R470T+ Load Balance Broadband Router Specification

General

Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3x, FCC, RoHS
Device Type Router
Connectivity Technology Wired
Data Link Protocol Ethernet, Fast Ethernet
Network / Transport Protocol TCP/IP, PPTP, L2TP, ICMP/IP, PPPoE, DHCP, DNS, DDNS
Remote Management Protocol HTTP
Features Firewall protection, DMZ port, NAT support, load balancing, DoS attack prevention, port mirroring, MAC address filtering, VPN passthrough, parental control, IP address filtering, domain blocking, SNTP support, Quality of Service (QoS), virtual server support, DHCP server, static IP mode, UPnP Media Server, bandwidth control, port triggering, dynamic IP mode, time based access control
Processor 400 MHz

Power

Power Device Internal power supply

Miscellaneous

Width 20.9 cm
Depth 12.6 cm
Height 2.6 cm
Compliant Standards FCC, RoHS
Cables Included 1 x network cable

Expansion / Connectivity

Interfaces WAN / LAN: 3 x 10Base-T/100Base-TX – RJ-45 ¦ LAN: 1 x 10Base-T/100Base-TX – RJ-45 ¦ WAN: 1 x 10Base-T/100Base-TX – RJ-45

Software / System Requirements

Software Included Drivers & Utilities

Dimensions & Weight

Width 20.9 cm
Depth 12.6 cm
Height 2.6 cm

Environmental Parameters

Min Operating Temperature 0 °C
Max Operating Temperature 40 °C
Humidity Range Operating 10 – 90% (non-condensing)
